Manufacturers Directly Provide Stainless Steel V-Shaped Shrapnel Compression Spring Inside The Positioning of The Pinball Buckle to The Drawing Sample Customiza
Product Name: Stainless Steel V-Shaped Shrapnel Compression Spring SEO Description: Get custom stainless steel V-shaped shrapnel compression springs directly from the manufacturer. Precision-made to your drawing sample.
Request a Quote

PRODUCTS DETAILS

Basic Info.

Surface Treatment
Nickel Plating, Chrome Plating, Zinc Plating ,Blac
Applications
Automotive,Electrical Equipment, Household Applian
Finish
Oil DIP,Passivation,Blacking, Zinc/Nickel/Chrome/S
Tube Clip Category
Compressed Springs, Coil Spring
Style
Flat;Leaf;Plate
Customization
Available
Transport Package
Plastic Box or Customized
Specification
Customized
Trademark
HND or Customized logo
Origin
China
HS Code
7320209000
Production Capacity
5000000/Year

Product Description

Shaped Spring

Customized Stainless Steel Flat Metal Retaining Hose Clamps Loaded Small V Shaped Spring Button Clip For Round Pipe Tube

Material		 Stainless Steel (SUS304,301.316 ect)
Paino/Music Wire ,Carbon Steel
65Mn, Alloy or as required

Finished		 Electroplating Zinc ,Nickel ,copper ,black and so on
Heating In different tempurture
Clean Passivation,Clean,Rust-Proof

Appliance		 All kinds of cars ,machinery, home appliance, electronic products, computers, power switches, sport equipment and more
Wire dia Range 0.1-20mm

Manufacturers Directly Provide Stainless Steel V-Shaped Shrapnel Compression Spring Inside The Positioning of The Pinball Buckle to The Drawing Sample Customiza Manufacturers Directly Provide Stainless Steel V-Shaped Shrapnel Compression Spring Inside The Positioning of The Pinball Buckle to The Drawing Sample Customiza Standard substance
Part No. HD Dia. HD Hgt. Material thickness Material width Min.
RoundTubing ID		 Max.
RoundTubing ID		 Min.
SquareTubing ID		 Max.
SquareTubing ID
All measurements are in inches (in)
HND-SC01 0.187 0.15 0.018 0.188 0.65 0.75 0.65 0.75
HND-SC02 0.187 0.175 0.018 0.188 0.3 0.4 0.3 0.4
HND-SC03 0.187 0.22 0.018 0.188 0.35 0.45 0.35 0.45
HND-SC04 0.187 0.28 0.018 0.188 0.4 0.87 0.4 0.87
HND-SC05 0.25 0.28 0.022 0.25 0.43 0.62 0.4 0.62
HND-SC06 0.25 0.28 0.022 0.25 0.7 0.88 0.7 0.88
HND-SC07 0.25 0.31 0.022 0.25 0.5 0.8 0.5 0.8
HND-SC08 0.25 0.31 0.022 0.25 0.5 0.88 0.5 0.88
HND-SC09 0.25 0.375 0.022 0.25 0.5 0.87 0.55 0.88
HND-SC10 0.25 0.281 0.018 0.21 0.5 0.8 0.5 0.8
HND-SC11 0.312 0.37 0.025 0.312 0.55 0.87 0.45 0.87
HND-SC12 0.3 0.325 0.025 0.375 0.6 1.2 0.5 1.12
HND-SC13 0.375 0.37 0.025 0.375 0.6 0.93 0.56 0.87
HND-SC14 0.365 0.325 0.025 0.375 0.65 1.2 0.65 1.2
HND-SC15 0.375 0.4 0.025 0.375 0.6 1.25 0.6 1.25
HND-SC16 0.375 0.46 0.025 0.375 0.65 1 0.6 1
HND-SC17 0.365 0.375 0.025 0.375 NMI0 NMI NMI NMI
HND-SC18 .365/.320 0.5 0.02 0.375 0.83 1.87 0.83 1.87
Products Details
Manufacturers Directly Provide Stainless Steel V-Shaped Shrapnel Compression Spring Inside The Positioning of The Pinball Buckle to The Drawing Sample Customiza Manufacturers Directly Provide Stainless Steel V-Shaped Shrapnel Compression Spring Inside The Positioning of The Pinball Buckle to The Drawing Sample Customiza Company Profile

XIAMEN HUANENGDA SPRING CO.,LTD

   Xiamen HuaNengDa Spring Co., Ltd. is located in Tong 'an District, Xiamen City, Fujian Province, China. It is a hardware factory specializing in R&D design, manufacture and sales of precision components. The company introduces domestic and foreign advanced equipment and production technology, adopts CNC high-precision computer machine, compression spring machine, CNC five-axis linkage machining center, CNC turning and milling compound, 300 tons of punch and other mechanical equipment,and employs senior engineers with more than ten years of work experience to debug mechanical equipment and customize production.
   With the business philosophy of honesty, pragmatism and excellence, HuaNengDa Spring Company is dedicated to serving customers at home and abroad. We hope that the products of HuaNengDa will help your business to be more brilliant, let us build a bright future in the high-tech era!
   The testimony is pragmatic and the attitude of the people. Quality service is the pursuit of the people!
Manufacturers Directly Provide Stainless Steel V-Shaped Shrapnel Compression Spring Inside The Positioning of The Pinball Buckle to The Drawing Sample Customiza HUANENGDA Production Line
Manufacturers Directly Provide Stainless Steel V-Shaped Shrapnel Compression Spring Inside The Positioning of The Pinball Buckle to The Drawing Sample Customiza Manufacturers Directly Provide Stainless Steel V-Shaped Shrapnel Compression Spring Inside The Positioning of The Pinball Buckle to The Drawing Sample Customiza Manufacturers Directly Provide Stainless Steel V-Shaped Shrapnel Compression Spring Inside The Positioning of The Pinball Buckle to The Drawing Sample Customiza
HUANENGDA Warehouse
Manufacturers Directly Provide Stainless Steel V-Shaped Shrapnel Compression Spring Inside The Positioning of The Pinball Buckle to The Drawing Sample CustomizaPacking & Delivery
Manufacturers Directly Provide Stainless Steel V-Shaped Shrapnel Compression Spring Inside The Positioning of The Pinball Buckle to The Drawing Sample Customiza
Our Service
Manufacturers Directly Provide Stainless Steel V-Shaped Shrapnel Compression Spring Inside The Positioning of The Pinball Buckle to The Drawing Sample Customiza
FAQ
1.Small order quantity is workable
From the initial sample design of the spring to the mass production of the springs, we can quickly reach your manufacturing goals and immediately provide the best products because we have an excellent production management system and expertly trained technical personnel.
2.Committed to high quality production
To keep HuaNengDa Springs at the forefront of the industry, we have implemented a stringent internal quality control system and regularly import the latest manufacturing equipment and instruments. Through our precise manufacturing technology and expert mold making process, we provide our customers with the best products and service.
3.Efficiency in manufacturing
Our company's machinery and equipment are controlled by CNC computers. In order to respond to international needs and standards, we continuously update and upgrade our equipment every year. Our machines effectively increase production capacity and save on manufacturing costs. The manufacturing department is the most important core of the whole company and by treating it with utmost importance, we reap great benefits in manufacturing efficiency.
4.Excellent customization services
HuaNengDa's R&D team designs and completes customized products according to the needs of customers. From the selection of materials to the function of the products, we can design and develop products to suite different customers' requirements. We are constantly involving ourselves in all aspects of the industry because only by having a complete view and analysis of the industry, can there be innovative breakthroughs.
Payment term
*T/T : 30% pre T/T, 70% before delivery.
*Trade Assurance
Service
*Delivery on time.
*Shipped by a convenient and cost-effective way.
*Good after-selling, 24 hours service for you.
Packing
*A: Poly bag, Plstic tray ,small box, carton.
*B: According to customers' requirements.
Delivery
*Sample: 7-10 days after deposit received.
*Batch goods: 12-15 days after samples approved.
