Engine Intake Valve Seat Exhaust Valve Seat Tool Turbocharger Repair Kit Sj150-7z/7y

12V190 repair tools, cylinder liner pickpocket, valve seat removal tool, valve guide removal tool, piston ring removal tool, piston removal tool, valve seat reamer, torque wrench, 190 valve spring removal tool.
Fork puller tool
Valve guide removal tool (specialized removal)
Spark Plug Sheath Removal Tool
Valve Spring Removal Tool
JICHAI DIESEL ENGINE REPAIR TOOLS 307.42.08 Cylinder Head Nut Removal Wrench Connecting Rod Bolt Removal Torque Wrench
2V190 Cylinder Liner Pulling Tool Diesel Engine Parts For Aftermarket Service

Jichai 190 main products are: 6190 parts, 8190 parts, 12V190 parts, Jichai H16V190 parts, gas engine parts, biogas generator set parts, gas engine parts, boat engine parts. Supply 190 parts, body, crankshaft, 12VB.03.00 diesel engine cylinder head assembly, gas engine cylinder head assembly, 16V gas engine cylinder head assembly, 190 connecting rod assembly, connecting rod tile, thrust tile, thrust plate, Z12VB.05.01C piston, 190 cylinder liner, supercharger (20GJ supercharger, SJ160 supercharger, J170 supercharger) intercooler. 12VB.22.00B water pump, JICHAI overhaul kit, complete car mat, 190 camshaft, air motor, electric starter motor, 3411 high elastic coupling, Changsha Zhengsheng piston ring set, 190 intake and exhaust valves and seats, three-core speed sensor, dashboard, STITT spark plug, ignition coil, 127.90.10 high voltage wire, ignition controller, 190 oil filter, 190 accessories 12VB.21.00 Oil Cooler, High Pressure Oil Pump, Governor, Centrifugal Filter, JICHAI Oil Filter, JICHAI 12V190 Parts, JICHAI Air Filter, JICHAI Filter, JICHAI Filter, JICHAI Narrow V-Belt, JICHAI Injector, JICHAI ZCK150S835 Injector Coupling, JICHAI ZCK150S840 Injector Coupling, 12V.29.00 Hand Crank Oil Pump, 307.54. 00 electric pre-supply oil pump, sea water pump, jichai coupling parts.

Jinan Guohua Green Power Equipment Co.,Ltd(JNGH),is a high-tech sales &service company of Jinan Diesel Engine Co., Ltd. Established in 2010,JNGH has formed a complete system in sales and after-sales of 190 series engine(jichai brand:6L190,8V190,12V190.16V190) after eight years experience.
Main business scope:
Early stage:Consultation,designation, supply and erection of engine-based power plants,including diesel generator,natural gas generator,coal gas generator and biogas generator.
Mid stage:Parts supply of jinan diesel engine(jichai/chidong brand).JNGH has two warehouses.One located in Jinan which supply the domestic north and south market.One located in Xinjiang province which supply the west market.Thus could delivery parts fast and guarantee the quality.
Later stage:JNGH also offer engine overhaul and maintenance service.With experienced engineer and professional skills,the problems could be easy solved.Not only the domestic China,Ghana,Kazakhstan,Vietnam and Myanmar also could see the trace of JNGH.

Jichai 190 cylinder head parts is one of the main parts of the diesel engine, its working conditions are harsh, the use of high requirements, the performance and reliability of the diesel engine have a great impact. For this reason, it is required to pay close attention to its working condition in the process of use, and regular inspection and maintenance.

1. Frequently check the lubrication condition of the rocker arm mechanism. When the diesel engine is running at low speed after starting or when it is pre-feeding pump oil before starting, open the upper cover of the cylinder head and observe whether there is oil overflow at the rocker arm bushing, and if it is found that there is no oil, it should be disassembled and cleaned immediately and clean the throttle valve at the oil pipe of the diesel engine on the machine body.

2. Strictly prevent the valve from sticking phenomenon. After the phenomenon of sticking in the valve, if start the diesel engine directly, it is easy to have an accident. Sticky phenomenon in the low temperature environment or poor oil quality is most likely to occur. Therefore, in the low temperature environment before starting the diesel engine, must be warmed up, so that the oil and cooling water temperature rises to more than 20C. Before starting must also manpower disk crankshaft I 2 weeks, no abnormal phenomena before starting. Should not be used in the process of long idling.

3. Check the cylinder head frequently for air, oil and water leakage. If leakage is found, check whether the cylinder head nut is loose, and tighten it evenly according to the specified torque if necessary. If the leakage phenomenon can not be eliminated, should check the relevant parts of the gasket is damaged, if necessary, replace the new parts.

4. Check the cooling condition of the cylinder head, the use of cooling water quality should be in strict accordance with the requirements, so as not to cause the cylinder head cooling waterway scaling and clogging. If the cylinder head temperature is found to be too high, should be removed from the cylinder head back to the mouth of the elbow connection, check whether there is serious scaling or clogging phenomenon, if necessary, should be cleaned up, dredging, so as not to cause poor cooling cylinder head, cooling "dead zone", causing valve sag and other malfunctions.

5. Regular testing and adjustment of valve lash
