Product Description
>> Introduction
>> Characteristic >> The complete vehicle adopts original engine that is imported from international renowned brand, Also, it introduces the constant power control system to give full swing to the engine power, and to provide the excavator with strong power.
>> hydraulic Medium excavator has both excellent environmental performance and large power, matched with ow fuel consumption design, operating costs are significantly reduced.
>> Leather seats, with seat belts and handrails, can be adjusted before and after, with adjustable rear corners.
>> German MA brand continental hydraulic hose is an international brand with stable and reliable quality.
>> The external hydraulic hose is equipped with spring retainer and spiral protection hose to avoid friction, collision, bending and other damage
>> The action levers are equipped with dust covers and portable handrails
>> The main console is composed of three parts. The overall shape is like a "fist", rich in tension, streamlined trend design, calm and domineering, which is in line with the aesthetics of the East and the West. The connector adopts stainless steel countersunk head gasket + countersunk head hexagon socket screw, which has good fastening and decorative effects.
>> The instrument integrated cover at the front is easy to disassemble, and the later maintenance of electrical components and main valve is particularly convenient
| The whole system is equippedwith big brand changchai engine,stable performance, strong power. | One-piece molding, not easy tobreak,The oil pipe is on the insideof the boom. Reinforced forearm design improves structure, disperses stress, stability and durability. | Simple operation mode,convenient maintenance,perfect technical supportand high reliability, highquality price-performanceratio and low use cost. |
| Reinforcement design, longer service life. | The hydraulic system uses reliable high-performance hydraulic compo-nents, combined with pilot hydraulicand mechanical operation modes,which is light, flexible and reliable.Ensure the movement of the machineand work more coordinated. | The crawler can be adjusted leftand right in the narrow scene,making it more convenient toenter and leave different scenes. All parts of walking have beenstrengthened as a whole, whichgreatly improves the reliability. |
| Description | Unit | XE215D | |||
| Operating weight | kg | 21900 | |||
| Bucket capacity | m³ | 0.8~1.3 | |||
| Engine | Model | Engine | QSB7 | ||
| Style | Direct injection | --- | √ | ||
| Four strokes | --- | √ | |||
| Water cooling | --- | √ | |||
| Turbo-charging | --- | √ | |||
| Air to air intercooler | --- | √ | |||
| No. of cylinders | --- | 6 | |||
| Output power | kW/ r/min | 135/2050 | |||
| torque/speed | N.m | 740/1250 | |||
| Displacement | L | 6.7 | |||
| Main performance | Travel speed(H/L) | km/h | 5.4/3.1 | ||
| Gradeability | % | 70 | |||
| Rotary speed | r/min | 11.8 | |||
| Ground pressure | kPa | 47.2 | |||
| Bucket digging force | kN | 149 | |||
| Arm digging force | kN | 111 | |||
| Hydraulic system | Main pump | -- | K7V125 | ||
| Rated flow of main pump | L/min | 2×225 | |||
| Main safety valve pressure | MPa | 34.3/37 | |||
| Pressure of pilot system | MPa | 3.9 | |||
| Oil Capacity | Fuel tank capacity | L | 400 | ||
| Hydraulic tank capacity | L | 220 | |||
| Engine oil capacity | L | 19.5 | |||
| Appearance size | Overall length | mm | 9625 | ||
| Overall width | mm | 2990 | |||
| Overall height | mm | 3100 | |||
| Width of platform | mm | 2830 | |||
| Length of crawler | mm | 4255 | |||
| Overall width of chassis | mm | 2990 | |||
| Width of crawler | mm | 600 | |||
| Wheel base of crawler | mm | 3462 | |||
| Crawler gauge | mm | 2390 | |||
| Clearance under counterweight | mm | 1050 | |||
| Min. ground clearance | mm | 476 | |||
| Min. rear-end swing radius | mm | 2890 | |||
| Working scope | Max. digging height | mm | 9620 | ||
| Max. dumping height | mm | 6780 | |||
| Max. digging depth | mm | 6680 | |||
| Max. digging depth at the range of level 8 feet | mm | 6500 | |||
| Max. vertical wall digging depth | mm | 5715 | |||
| Max. digging reach | mm | 9940 | |||
| Min. swing radius | mm | 3530 | |||
