Basic Info.
Model NO.
Customized
Transport Package
Polybag-Paper Carton-Wooden Case
Specification
Customized
Trademark
znspring
Origin
Dezhou China
HS Code
4016999000
Production Capacity
50 Sets / Day
Product Description
![Rubber Metal Coil Compound Spring for Subway Bogie](http://img6.grofrom.com/www.zhiyuspringgroup.com/226f3j00tQIlgeUWVwuP/Rubber-Metal-Coil-Compound-Spring-for-Subway-Bogie.webp)
![Rubber Metal Coil Compound Spring for Subway Bogie](http://img6.grofrom.com/www.zhiyuspringgroup.com/226f3j00QTIizFUCOdgL/Rubber-Metal-Coil-Compound-Spring-for-Subway-Bogie.webp)
Specification D*H | Outer diameter D(mm) | Free height H(mm) | Diameter screw hole(mm) | Product stiffness | Compound hardness Shore A | Working temperature ºC |
204*195 | 204 | 195 | 111 | Vertical 1.08(1±10%)kN/mm Radial 16.2(1±15%)kN/mm Torsion 10.8(1±10%)MN.m/rad | 55±5 | -35ºC--+80ºC |
![Rubber Metal Coil Compound Spring for Subway Bogie](http://img6.grofrom.com/www.zhiyuspringgroup.com/226f3j00vGDWzirtqlgj/Rubber-Metal-Coil-Compound-Spring-for-Subway-Bogie.webp)
