Mini Bigger Small Mini Crawler Excavator 20 Ton Cheap Bucket Excavators for Sale

Looking for a 20 ton mini crawler excavator for sale? Our factory offers cheap bucket excavators with high quality. Buy now! Fast delivery available.
Request a Quote

PRODUCTS DETAILS

Basic Info.

Model NO.
XE200DA
Bucket Capacity
0.32~0.61m3
Size
Medium-Sized
Certification
CE
Condition
New
Operating Weight
20000kg
Power
135kw
Rated Speed
2050r/Min
Maximum Digging Height
9680mm
Maximum Digging Depth
6460mm
Transport Package
40hq Container
Specification
20000kg
Trademark
KAITIAN
Origin
China
Production Capacity
2000sets/ Year

Product Description

Mini bigger Small Mini Crawler Excavator 20 Ton Cheap Bucket Excavators For Sale
>> Introduction
XE200DA hydraulic excavator is suitable for earth and stone construction projects such as municipal construction, highway bridges, housing construction, road engineering, farmland water conservancy construction, port construction and so on, it has features of good flexibility and maneuverability, low fuel consumption, high construction efficiency.
New generation environmental engine is adopted in this machine, which has both excellent environmental performance and large power, matched with ow fuel consumption design, operating costs are significantly reduced.
Mini Bigger Small Mini Crawler Excavator 20 Ton Cheap Bucket Excavators for Sale >> Characteristic
>> The complete vehicle adopts original engine that is imported from international renowned brand, Also, it introduces the constant power control system to give full swing to the engine power, and to provide the excavator with strong power.
>> hydraulic Medium excavator has both excellent environmental performance and large power, matched with ow fuel consumption design, operating costs are significantly reduced.
>> Leather seats, with seat belts and handrails, can be adjusted before and after, with adjustable rear corners.
>> German MA brand continental hydraulic hose is an international brand with stable and reliable quality.
>> The external hydraulic hose is equipped with spring retainer and spiral protection hose to avoid friction, collision, bending and other damage
>> The action levers are equipped with dust covers and portable handrails
>> The main console is composed of three parts. The overall shape is like a "fist", rich in tension, streamlined trend design, calm and domineering, which is in line with the aesthetics of the East and the West. The connector adopts stainless steel countersunk head gasket + countersunk head hexagon socket screw, which has good fastening and decorative effects.
>> The instrument integrated cover at the front is easy to disassemble, and the later maintenance of electrical components and main valve is particularly convenient
Mini Bigger Small Mini Crawler Excavator 20 Ton Cheap Bucket Excavators for Sale
The whole system is equippedwith big brand changchai engine,stable performance, strong power.

One-piece molding, not easy tobreak,The oil pipe is on the insideof the boom.
Reinforced forearm design improves structure, disperses stress, stability and durability.
Simple operation mode,convenient maintenance,perfect technical supportand high reliability, highquality price-performanceratio and low use cost.


Mini Bigger Small Mini Crawler Excavator 20 Ton Cheap Bucket Excavators for Sale

Reinforcement design, longer service life.





The hydraulic system uses reliable high-performance hydraulic compo-nents, combined with pilot hydraulicand mechanical operation modes,which is light, flexible and reliable.Ensure the movement of the machineand work more coordinated. The crawler can be adjusted leftand right in the narrow scene,making it more convenient toenter and leave different scenes.
All parts of walking have beenstrengthened as a whole, whichgreatly improves the reliability.

Mini Bigger Small Mini Crawler Excavator 20 Ton Cheap Bucket Excavators for Sale

>> Certification
Model
Unit
XE200DA
Operating weight
Kg
21200
Bucket capacity
0.93~1.1
Engine
Model
/
QSB7
No. of cylinders
/
6
Rated power/speed
kw/rpm
135/2050
Maximum torque/speed
N.m
740/1250
Displacement
L
6.7
Main performance
Travel speed(H/L)
km/h
5.3/2.9
Swing speed
r/min
11.6
Gradeability
°
≤35
Ground pressure
kPa
46.9
Bucket digging force
kN
149
Arm digging force
kN
121
Maximum tractive force
kN
184
Hydraulic system
Main pump
/
Two piston pumps
Rated flow of main pump
L/min
2×209
Main safety valve pressure
MPa
34.3/37
Travel system pressure
MPa
34.3
Swing system pressure
MPa
28
Pilot system pressure
MPa
3.9
Oil Capacity
Fuel tank capacity
L
400
Hydraulic tank capacity
L
220
Engine oil capacity
L
24
Appearance size
Overall length
mm
9625
Overall width
mm
2910
Overall height
mm
3100
Width of platform
mm
2830
Track length
mm
4155
Overall width of chassis
mm
2890
Track shoe width
mm
600
Length to center of rollers
mm
3366
Track gauge
mm
2290
Counterweight clearance
mm
1050
Min. ground clearance
mm
486
Min. tail swing radius
mm
2890
Track height
mm
940
Working scope
Max. digging height
mm
9680
Max. dumping height
mm
6815
Max. digging depth
mm
6460
Maximum depth cut for 2240mm(8 ft) level bottom
mm
6275
Max. vertical wall digging depth
mm
5590
Max. digging radius
mm
9790
Min. swing radius
mm
3530
>> Production Process
Mini Bigger Small Mini Crawler Excavator 20 Ton Cheap Bucket Excavators for Sale>> Package & Delivery
Mini Bigger Small Mini Crawler Excavator 20 Ton Cheap Bucket Excavators for Sale>> ServiceMini Bigger Small Mini Crawler Excavator 20 Ton Cheap Bucket Excavators for Sale


>> Pre-sale service

Acting as a good adviser, our well-trained sales groups and professional technical team propose most rational solutions for our valued client as per practical project requirement.

>> Select suitable model & matched equipment.

>> Strong technical support. Reply clients' questions within 24 hours.



>> Service During Sales

We have responsible team from raw material to finished products, and guarantee 100% pass rate.

>> Design and manufacture products basis of client's special requirement

>> Inspect each machine & matched accessories strictly before delivery

>> Timely inform client of production progress.



>> After Sales Service

We're always with you in after-sale service.

>> We can arrange related after-sales representatives for debugging and training at worksite when starting up.

>> E-mail, call or door-to-door service in later using.




Mini Bigger Small Mini Crawler Excavator 20 Ton Cheap Bucket Excavators for Sale>> Overseas Project
Mini Bigger Small Mini Crawler Excavator 20 Ton Cheap Bucket Excavators for Sale
>> Exhibition
Mini Bigger Small Mini Crawler Excavator 20 Ton Cheap Bucket Excavators for Sale
>> About KAITIAN
Mini Bigger Small Mini Crawler Excavator 20 Ton Cheap Bucket Excavators for SaleMini Bigger Small Mini Crawler Excavator 20 Ton Cheap Bucket Excavators for Sale
Beijing Jincheng Mining Technology Co.,Ltd(JCDRILL) provide users high quality Mining & Drilling solutions,we always focus on the strategic conception of "Survival by quality, Development by credit''.

We have specilized in research, development and produce of rock blasting drilling rig, water well drilling rig, diamond core drilling rig, anchor drilling rig, and relative accessories & drilling services. constantly provide professional drilling solutions for all customers with our advanced technology, excellent equipment, strict testing means and good service network,which establish our brand "JCDRILL" a good image of market, now,we products account for 50% of domestic market and have been export to more than 40 countries, and we awarded ISO9001: 2000 in November, 2002.

With excellent technology and solid market service capabilities, we have both a sound marketing system and excellent service support system, which help us win confidence of customers both at home and abroad,we can provide drilling rig users with high quality professional air compressor solution and relative after-sales service also.
Mini Bigger Small Mini Crawler Excavator 20 Ton Cheap Bucket Excavators for Sale >> Certification
Mini Bigger Small Mini Crawler Excavator 20 Ton Cheap Bucket Excavators for Sale

>> FAQ

Q: Are you original manufacturer?



Q: Which payment terms are available to us?

Q: Which Incoterms 2010 terms can we work?

A: Yes, we JCDRILL is a official leading manufacture in drilling machinery in China and we have the whole series products you need.

A: T/T term or L/C term. On T/T term, 30% down payment is required in advance, and 70%  balance shall be settled before shipment. On L/C term, a 100% irrevocable L/C without "soft clauses" can be accepted.

A: We JCDRILL are a professional and international company, accept all Incoterms 2010 terms, normally we work on FOB, CIF, CFR, CIP.

Q: How long will the delivery time take? Q: How about after sales service?

Q:Spare Parts When You Need Them


A: Normally products will take about 3-15 days to produce the ordered machines. Most of the time, we can have an immediate delivery of our regular machines in 15 days.

A: 365×24 Year-round Service We are committed to year-round 24-hour service even during holidays, in line with our policy of always providing "a response within 15 minutes and job completion within 24 hours."

A:We have spare parts centers across continents that stock specialist spare parts. We promise that spare parts will be delivered within 72 hours or no more than one week.
