27 Ton Electric Hydraulic Excavators Micro Digger Crawler Excavators

Get top-notch 27 Ton Electric Hydraulic Excavators Micro Digger Crawler Excavators from our factory. High quality and durable construction equipment at unbeatable prices.
Request a Quote

PRODUCTS DETAILS

Basic Info.

Model NO.
XE270DK
Bucket Capacity
0.32~0.61m3
Size
Medium-Sized
Certification
CE
Condition
New
Operating Weight
26500kg
Power
150kw
Rated Speed
11.4r/Min
Maximum Digging Height
10095mm
Maximum Digging Depth
6925mm
Transport Package
40hq Container
Specification
27 T
Trademark
KAITIAN
Origin
China
Production Capacity
2000sets/ Year

Product Description

27 Ton Electric Hydraulic Excavators Micro Digger Crawler Excavators
>> Introduction
XE270DK hydraulic excavator is suitable for earth and stone construction projects such as municipal construction, highway bridges, housing construction, road engineering, farmland water conservancy construction, port construction and so on, it has features of good flexibility and maneuverability, low fuel consumption, high construction efficiency.
New generation environmental engine is adopted in this machine, which has both excellent environmental performance and large power, matched with ow fuel consumption design, operating costs are significantly reduced.
27 Ton Electric Hydraulic Excavators Micro Digger Crawler Excavators >> Characteristic
>> The complete vehicle adopts original engine that is imported from international renowned brand, Also, it introduces the constant power control system to give full swing to the engine power, and to provide the excavator with strong power.
>> hydraulic Medium excavator has both excellent environmental performance and large power, matched with ow fuel consumption design, operating costs are significantly reduced.
>> Leather seats, with seat belts and handrails, can be adjusted before and after, with adjustable rear corners.
>> German MA brand continental hydraulic hose is an international brand with stable and reliable quality.
>> The external hydraulic hose is equipped with spring retainer and spiral protection hose to avoid friction, collision, bending and other damage
>> The action levers are equipped with dust covers and portable handrails
>> The main console is composed of three parts. The overall shape is like a "fist", rich in tension, streamlined trend design, calm and domineering, which is in line with the aesthetics of the East and the West. The connector adopts stainless steel countersunk head gasket + countersunk head hexagon socket screw, which has good fastening and decorative effects.
>> The instrument integrated cover at the front is easy to disassemble, and the later maintenance of electrical components and main valve is particularly convenient
27 Ton Electric Hydraulic Excavators Micro Digger Crawler Excavators
The whole system is equippedwith big brand changchai engine,stable performance, strong power.

One-piece molding, not easy tobreak,The oil pipe is on the insideof the boom.
Reinforced forearm design improves structure, disperses stress, stability and durability.
Simple operation mode,convenient maintenance,perfect technical supportand high reliability, highquality price-performanceratio and low use cost.


27 Ton Electric Hydraulic Excavators Micro Digger Crawler Excavators

Reinforcement design, longer service life.





The hydraulic system uses reliable high-performance hydraulic compo-nents, combined with pilot hydraulicand mechanical operation modes,which is light, flexible and reliable.Ensure the movement of the machineand work more coordinated. The crawler can be adjusted leftand right in the narrow scene,making it more convenient toenter and leave different scenes.
All parts of walking have beenstrengthened as a whole, whichgreatly improves the reliability.

27 Ton Electric Hydraulic Excavators Micro Digger Crawler Excavators

>> Certification
Engine
Engine model
-
XE270DK
Rated power
kw/rpm
150/2050
Max. torque
N.m/rpm
825/1250
No. of cylinders
-
6
Displacement
L
6.7


Main performance
Walking speed
km/h
6.1/3.8
Rotary speed
r/min
11.4
Climbing ability
°
35
Ground pressure
kPa
52.1
Bucket digging force
kN
185
Arm digging force
kN
129
Max. traction
kN
205


Hydraulic system
Main pump rated flow
L/min
259*2
Main safety valve pressure
MPa
34.3/37
Travel system pressure
MPa
34.3
Rotary system pressure
MPa
25
Pilot system pressure
MPa
3.9
Oil capacity
Fuel tank capacity
L
400
Hydraulic tank volume
L
220
Working dimensions
Max. digging height
mm
10095
Max. digging depth
mm
6925
Max. digging radius
mm
10240
Min. turning radius
mm
3510
Boom length
mm
6000
Arm length
mm
2964
>> Production Process
27 Ton Electric Hydraulic Excavators Micro Digger Crawler Excavators>> Package & Delivery
27 Ton Electric Hydraulic Excavators Micro Digger Crawler Excavators>> Service27 Ton Electric Hydraulic Excavators Micro Digger Crawler Excavators


>> Pre-sale service

Acting as a good adviser, our well-trained sales groups and professional technical team propose most rational solutions for our valued client as per practical project requirement.

>> Select suitable model & matched equipment.

>> Strong technical support. Reply clients' questions within 24 hours.



>> Service During Sales

We have responsible team from raw material to finished products, and guarantee 100% pass rate.

>> Design and manufacture products basis of client's special requirement

>> Inspect each machine & matched accessories strictly before delivery

>> Timely inform client of production progress.



>> After Sales Service

We're always with you in after-sale service.

>> We can arrange related after-sales representatives for debugging and training at worksite when starting up.

>> E-mail, call or door-to-door service in later using.




27 Ton Electric Hydraulic Excavators Micro Digger Crawler Excavators>> Overseas Project
27 Ton Electric Hydraulic Excavators Micro Digger Crawler Excavators
>> Exhibition
27 Ton Electric Hydraulic Excavators Micro Digger Crawler Excavators
>> About KAITIAN
27 Ton Electric Hydraulic Excavators Micro Digger Crawler Excavators27 Ton Electric Hydraulic Excavators Micro Digger Crawler Excavators
Beijing Jincheng Mining Technology Co.,Ltd(JCDRILL) provide users high quality Mining & Drilling solutions,we always focus on the strategic conception of "Survival by quality, Development by credit''.

We have specilized in research, development and produce of rock blasting drilling rig, water well drilling rig, diamond core drilling rig, anchor drilling rig, and relative accessories & drilling services. constantly provide professional drilling solutions for all customers with our advanced technology, excellent equipment, strict testing means and good service network,which establish our brand "JCDRILL" a good image of market, now,we products account for 50% of domestic market and have been export to more than 40 countries, and we awarded ISO9001: 2000 in November, 2002.

With excellent technology and solid market service capabilities, we have both a sound marketing system and excellent service support system, which help us win confidence of customers both at home and abroad,we can provide drilling rig users with high quality professional air compressor solution and relative after-sales service also.
27 Ton Electric Hydraulic Excavators Micro Digger Crawler Excavators >> Certification
27 Ton Electric Hydraulic Excavators Micro Digger Crawler Excavators

>> FAQ

Q: Are you original manufacturer?



Q: Which payment terms are available to us?

Q: Which Incoterms 2010 terms can we work?

A: Yes, we JCDRILL is a official leading manufacture in drilling machinery in China and we have the whole series products you need.

A: T/T term or L/C term. On T/T term, 30% down payment is required in advance, and 70%  balance shall be settled before shipment. On L/C term, a 100% irrevocable L/C without "soft clauses" can be accepted.

A: We JCDRILL are a professional and international company, accept all Incoterms 2010 terms, normally we work on FOB, CIF, CFR, CIP.

Q: How long will the delivery time take? Q: How about after sales service?

Q:Spare Parts When You Need Them


A: Normally products will take about 3-15 days to produce the ordered machines. Most of the time, we can have an immediate delivery of our regular machines in 15 days.

A: 365×24 Year-round Service We are committed to year-round 24-hour service even during holidays, in line with our policy of always providing "a response within 15 minutes and job completion within 24 hours."

A:We have spare parts centers across continents that stock specialist spare parts. We promise that spare parts will be delivered within 72 hours or no more than one week.
